SUNSYNK HYBRID INVERTER

1. RATED POWER: 50 000W
2. MIN PPT VOLTAGE: 150V
3. MAX PPT VOLTAGE: 850V
4. MAX INPUT VOLTAGE: 1000V
5. MAX DC POWER: 65 000W
6. MAX AC POWER: 55 000W
7. SURGE AC POWER: 75 000W
8. MAX DC CURRENT: 144A
9. MAX DC INPUTS: 8
10. MPPT QUANTITY: 4
11. CONNECTORS: MC4
12. EFFICIENCY: 99.9%
13. WEIGHT: 75KG

Product Features

1. The Sunsynk 50kW three phase high voltage hybrid Inverter is the ideal commercial inverter for managing power flow from multiple sources such as solar, main electrical grid and generator.
2. Four MPPT trackers giving allowance to flexible PV array configurations.
3. Allows DC oversizing up to 30% more than the rated AC power.
4. Unit can be operated without batteries (using PV and grid power).
5. Supports Wi-Fi remote monitoring as standard.
6. Type II DC/AC SPD as standard.
7. Overload, Over Temperature and Short Circuit Protection as standard.
8. Up to 5 x 50kW inverters can be connected in a parallel configuration, with each inverter having its own batteries connected to it.

PLEASE NOTE:

For systems containing high voltage batteries or inverters requiring a high voltage DC battery supply greater than 48V, the following is required and should be supplied:

1. Installer must be a 3-Phase Electrician registered with Department of Labour (red seal).
2. Installer must have product specific training prior to installation.
3. Specific manufacturers may require training prior to installation for warranty conditions.
4. All installer companies must adhere to the above, non-compliance will lead to product warranty invalidation
